Cablecam with DJI Ronin
All parts are made of CNC machined Aluminum with utmost precision and care, which offers 10kg/22lb of payload.
The Sky-Walker Cable Cam System provides a maximum speed of 40 km/hr without payload & 25km/hr with maximum payload and covers a long 450-meter range.
The combination of a 24V brushed DC motor with an efficient Motor Driver offers the highest level of performance.
Its highly sophisticated wireless remote-control system guarantees accurate operation and a long battery-life experience.
The onboard battery power lets you work smoothly for 20-25 minutes with a payload of up to 10kg/22lb, and it is easily detachable without disturbing the workflow.
The 24V brushed DC motor has enough torque to drive the camera rig without needing a gearbox that delivers silent footage.
It is the first synchronous regenerative motor driver in its class, allowing very fast stops and reverses.
And it is robust enough to supply a peak current of max 91A.
It has an overcurrent & thermal protection features which means your driver will never get damaged by accidental stalls or by hooking up a big motor.
The high-precision encoder motor works with gear that is mounted on the End wheel to ensure accurate control of movements.
It helps determine speed, position, distance, and acceleration, so every movement is perfectly smooth.
